Fuse link CH14x51 aR 25A/690V 002635013
Specifications
- ETI Code:
- 002635013
- Description:
- CH14x51 aR 25A/690V
- Class name:
- Fuse link
- efuse:
- 1
- Product group:
- Semiconductor Protection
- Type:
- CH
- Size:
- 14x51
- Rated current (A):
- 25
- Rated AC voltage (V):
- 690
- Characteristics:
- aR
- Breaking capacity AC (kA):
- 200
- Breaking capacity DC (kA):
- 50
- Application:
- For protection of semiconductor devices
- Power dissipation (W):
- 7
- Operating joule integral (A2s):
- 320
- Standards:
- IEC 60269-4
Documents
Logistic Data
Product
- EAN code for a single product
- 3838895362548
- Net weight of the product
- 0.039 kg
- Customs tariff
- 85361050
- logis_net_width
- 14 mm
- logis_net_height
- 51 mm
- logis_net_depth
- 14 mm
Transport packaging
- Transport packaging quantity
- 10
- EAN code for a transport packaging
- 3838895356271
- Transport packaging weight
- 0.22 kg
- Pallet quantity
- 31570
ETIM Clasification
- Classification
- EC002704
- Class name
- Cylindrical fuse
- Construction size
- CH14
- Rated current
- 25
- Max. rated operation voltage Ue AC
- 690
- Application
- For protection of semiconductor devices
- Size
- 14x51 mm
- Utilization category
- Other
- Nominal current
- 25A
- Breaking capacity
- 200kA
