Items:
0
004671271
ED2 125/3
- Class name:
- Switch disconnector
- Rated current (A):
- 125
- Rated short-circuit making capacity Icm:
- 3,6
- Number of poles:
- 3
- Rated short-time withstand current Icw at 0,3s (kA):
- 2
004671272
ED2 160/3
- Class name:
- Switch disconnector
- Rated current (A):
- 160
- Rated short-circuit making capacity Icm:
- 6
- Number of poles:
- 3
- Rated short-time withstand current Icw at 0,3s (kA):
- 3
004671273
ED2 250/3
- Class name:
- Switch disconnector
- Rated current (A):
- 250
- Rated short-circuit making capacity Icm:
- 6
- Number of poles:
- 3
- Rated short-time withstand current Icw at 0,3s (kA):
- 3
004671274
ED2 400/3
- Class name:
- Switch disconnector
- Rated current (A):
- 400
- Rated short-circuit making capacity Icm:
- 9
- Number of poles:
- 3
- Rated short-time withstand current Icw at 0,3s (kA):
- 5
004671275
ED2 630/3
- Class name:
- Switch disconnector
- Rated current (A):
- 630
- Rated short-circuit making capacity Icm:
- 9
- Number of poles:
- 3
- Rated short-time withstand current Icw at 0,3s (kA):
- 5
004672370
ED2 800/3
- Class name:
- Switch disconnector
- Rated current (A):
- 800
- Rated short-circuit making capacity Icm:
- 17
- Number of poles:
- 3
- Rated short-time withstand current Icw at 0,3s (kA):
- 10
004672373
ED2 1000/3
- Class name:
- Switch disconnector
- Rated current (A):
- 1000
- Rated short-circuit making capacity Icm:
- 17
- Number of poles:
- 3
- Rated short-time withstand current Icw at 0,3s (kA):
- 10
004672371
ED2 1250/3
- Class name:
- Switch disconnector
- Rated current (A):
- 1250
- Rated short-circuit making capacity Icm:
- 32
- Number of poles:
- 3
- Rated short-time withstand current Icw at 0,3s (kA):
- 15
004672374
ED2 1250/3 PI 3C
- Class name:
- Switch disconnector
- Rated current (A):
- 1250
- Rated short-circuit making capacity Icm:
- 32
- Number of poles:
- 3
- Rated short-time withstand current Icw at 0,3s (kA):
- 15
004672372
ED2 1600/3 FC
- Class name:
- Switch disconnector
- Rated current (A):
- 1600
- Rated short-circuit making capacity Icm:
- 45
- Number of poles:
- 3
- Rated short-time withstand current Icw at 0,3s (kA):
- 20
004671276
ED2 125/4
- Class name:
- Switch disconnector
- Rated current (A):
- 125
- Rated short-circuit making capacity Icm:
- 3,6
- Number of poles:
- 4
- Rated short-time withstand current Icw at 0,3s (kA):
- 2
004671277
ED2 160/4
- Class name:
- Switch disconnector
- Rated current (A):
- 160
- Rated short-circuit making capacity Icm:
- 6
- Number of poles:
- 4
- Rated short-time withstand current Icw at 0,3s (kA):
- 3
004671278
ED2 250/4
- Class name:
- Switch disconnector
- Rated current (A):
- 250
- Rated short-circuit making capacity Icm:
- 6
- Number of poles:
- 4
- Rated short-time withstand current Icw at 0,3s (kA):
- 3
004671279
ED2 400/4
- Class name:
- Switch disconnector
- Rated current (A):
- 400
- Rated short-circuit making capacity Icm:
- 9
- Number of poles:
- 4
- Rated short-time withstand current Icw at 0,3s (kA):
- 5
004671280
ED2 630/4
- Class name:
- Switch disconnector
- Rated current (A):
- 630
- Rated short-circuit making capacity Icm:
- 9
- Number of poles:
- 4
- Rated short-time withstand current Icw at 0,3s (kA):
- 5
004672380
ED2 800/4
- Class name:
- Switch disconnector
- Rated current (A):
- 800
- Rated short-circuit making capacity Icm:
- 17
- Number of poles:
- 4
- Rated short-time withstand current Icw at 0,3s (kA):
- 10
004672383
ED2 1000/4
- Class name:
- Switch disconnector
- Rated current (A):
- 1000
- Rated short-circuit making capacity Icm:
- 17
- Number of poles:
- 4
- Rated short-time withstand current Icw at 0,3s (kA):
- 10
004672381
ED2 1250/4
- Class name:
- Switch disconnector
- Rated current (A):
- 1250
- Rated short-circuit making capacity Icm:
- 32
- Number of poles:
- 4
- Rated short-time withstand current Icw at 0,3s (kA):
- 15
004672382
ED2 1600/4 FC
- Class name:
- Switch disconnector
- Rated current (A):
- 1600
- Rated short-circuit making capacity Icm:
- 45
- Number of poles:
- 4
- Rated short-time withstand current Icw at 0,3s (kA):
- 20
