Filters
Filter type
Clear all
Expand all
Open all
Rated AC voltage (V)
18
18
18
17
15
Rated current (A)
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
4
4
3
Size
18
18
18
17
15
Type
86
VVA (without striker pin)
Items:
0
004221102
VVA3 7,2kV/1A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 12
- Cold resistance (mΩ):
- 1170
- Rated current (A):
- 1
- Type:
- NEW VVA without striker
004221103
VVA3 7,2kV/2A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 12
- Cold resistance (mΩ):
- 580
- Rated current (A):
- 2
- Type:
- NEW VVA without striker
004221104
VVA3 7,2kV/4A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 20
- Cold resistance (mΩ):
- 370
- Rated current (A):
- 4
- Type:
- NEW VVA without striker
004221105
VVA3 7,2kV/6A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 25
- Cold resistance (mΩ):
- 260
- Rated current (A):
- 6
- Type:
- NEW VVA without striker
004221106
VVA3 7,2kV/6,3A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 25
- Cold resistance (mΩ):
- 260
- Rated current (A):
- 6,3
- Type:
- NEW VVA without striker
004221107
VVA3 7,2kV/10A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 43
- Cold resistance (mΩ):
- 75
- Rated current (A):
- 10
- Type:
- NEW VVA without striker
004221108
VVA3 7,2kV/16A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 56
- Cold resistance (mΩ):
- 44
- Rated current (A):
- 16
- Type:
- NEW VVA without striker
004221109
VVA3 7,2kV/20A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 70
- Cold resistance (mΩ):
- 27
- Rated current (A):
- 20
- Type:
- NEW VVA without striker
004221110
VVA3 7,2kV/25A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 87
- Cold resistance (mΩ):
- 21
- Rated current (A):
- 25
- Type:
- NEW VVA without striker
004221111
VVA3 7,2kV/31,5A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 110
- Cold resistance (mΩ):
- 18
- Rated current (A):
- 31,5
- Type:
- NEW VVA without striker
004221112
VVA3 7,2kV/32A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 110
- Cold resistance (mΩ):
- 18
- Rated current (A):
- 32
- Type:
- NEW VVA without striker
004221113
VVA3 7,2kV/40A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 140
- Cold resistance (mΩ):
- 13
- Rated current (A):
- 40
- Type:
- NEW VVA without striker
004221114
VVA3 7,2kV/50A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 175
- Cold resistance (mΩ):
- 10.5
- Rated current (A):
- 50
- Type:
- NEW VVA without striker
004221115
VVA3 7,2kV/63A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 220
- Cold resistance (mΩ):
- 7.5
- Rated current (A):
- 63
- Type:
- NEW VVA without striker
004221116
VVA3 7,2kV/80A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 280
- Cold resistance (mΩ):
- 5.9
- Rated current (A):
- 80
- Type:
- NEW VVA without striker
004221117
VVA3 7,2kV/100A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 360
- Cold resistance (mΩ):
- 4.8
- Rated current (A):
- 100
- Type:
- NEW VVA without striker
004221118
VVA3 7,2kV/125A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 450
- Cold resistance (mΩ):
- 3.9
- Rated current (A):
- 125
- Type:
- NEW VVA without striker
004221119
VVA3 7,2kV/160A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 600
- Cold resistance (mΩ):
- 3
- Rated current (A):
- 160
- Type:
- NEW VVA without striker
004231102
VVA3 12kV/1A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 12
- Cold resistance (mΩ):
- 1970
- Rated current (A):
- 1
- Type:
- NEW VVA without striker
004231103
VVA3 12kV/2A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 12
- Cold resistance (mΩ):
- 980
- Rated current (A):
- 2
- Type:
- NEW VVA without striker
004231104
VVA3 12kV/4A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 20
- Cold resistance (mΩ):
- 650
- Rated current (A):
- 4
- Type:
- NEW VVA without striker
004231105
VVA3 12kV/6A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 25
- Cold resistance (mΩ):
- 435
- Rated current (A):
- 6
- Type:
- NEW VVA without striker
004231106
VVA3 12kV/6,3A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 25
- Cold resistance (mΩ):
- 435
- Rated current (A):
- 6,3
- Type:
- NEW VVA without striker
004231107
VVA3 12kV/10A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 43
- Cold resistance (mΩ):
- 130
- Rated current (A):
- 10
- Type:
- NEW VVA without striker
004231108
VVA3 12kV/16A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 56
- Cold resistance (mΩ):
- 70
- Rated current (A):
- 16
- Type:
- NEW VVA without striker
004231109
VVA3 12kV/20A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 70
- Cold resistance (mΩ):
- 44
- Rated current (A):
- 20
- Type:
- NEW VVA without striker
004231110
VVA3 12kV/25A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 87
- Cold resistance (mΩ):
- 33
- Rated current (A):
- 25
- Type:
- NEW VVA without striker
004231111
VVA3 12kV/31,5A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 110
- Cold resistance (mΩ):
- 29
- Rated current (A):
- 31,5
- Type:
- NEW VVA without striker
004231112
VVA3 12kV/32A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 110
- Cold resistance (mΩ):
- 29
- Rated current (A):
- 32
- Type:
- NEW VVA without striker
004231113
VVA3 12kV/40A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 140
- Cold resistance (mΩ):
- 21.5
- Rated current (A):
- 40
- Type:
- NEW VVA without striker
004231114
VVA3 12kV/50A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 175
- Cold resistance (mΩ):
- 16.5
- Rated current (A):
- 50
- Type:
- NEW VVA without striker
004231115
VVA3 12kV/63A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 220
- Cold resistance (mΩ):
- 12
- Rated current (A):
- 63
- Type:
- NEW VVA without striker
004231116
VVA3 12kV/80A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 280
- Cold resistance (mΩ):
- 9
- Rated current (A):
- 80
- Type:
- NEW VVA without striker
004231117
VVA3 12kV/100A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 360
- Cold resistance (mΩ):
- 6.7
- Rated current (A):
- 100
- Type:
- NEW VVA without striker
004231118
VVA3 12kV/125A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 450
- Cold resistance (mΩ):
- 5.2
- Rated current (A):
- 125
- Type:
- NEW VVA without striker
004231119
VVA3 12kV/160A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 600
- Cold resistance (mΩ):
- 4.1
- Rated current (A):
- 160
- Type:
- NEW VVA without striker
004241102
VVA3 17,5kV/1A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 12
- Cold resistance (mΩ):
- 2800
- Rated current (A):
- 1
- Type:
- NEW VVA without striker
004241103
VVA3 17,5kV/2A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 12
- Cold resistance (mΩ):
- 1400
- Rated current (A):
- 2
- Type:
- NEW VVA without striker
004241104
VVA3 17,5kV/4A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 20
- Cold resistance (mΩ):
- 900
- Rated current (A):
- 4
- Type:
- NEW VVA without striker
004241105
VVA3 17,5kV/6A
- Class name:
- Fuse link
- Rated minimum breaking current (A):
- 25
- Cold resistance (mΩ):
- 670
- Rated current (A):
- 6
- Type:
- NEW VVA without striker
