Fuse link NH2 gG 200A/400V MET 004113846

Specifications

ETI Code:
004113846
Description:
NH2 gG 200A/400V MET
Class name:
Fuse link
efuse:
1
Type:
NH
Size:
NH2
Rated current (A):
200
Characteristics:
gG
Application:
As metering fuse with strip fuse switch disconnector and fuse switch disconnector
Indicator:
Top fuse status indicator
Power dissipation (W):
12
Standards:
IEC EN 60269-1

Documents

Product

EAN code for a single product

Net weight of the product
0.6  kg
Customs tariff
85361090

Level 1 Packaging

Basic packaging quantity
1
EAN code for a basic packaging
3838895618430
Basic packaging weight
0.6  kg

Level 2 Packaging

Transport packaging quantity
16
EAN code for a transport packaging
3838895618447
Transport packaging weight
10  kg
Pallet quantity
832
Classification
EC000055
Class name
Low Voltage HRC fuse
Construction size
NH2
Rated current
200
Rated voltage
400
Voltage type
AC
Rated switching capacity
50
Utilization category
gL/gG (cable protection/equipment protection)
Type of fuse status indicator
Top fuse status indicator
ETIM Classification – Version 7.0
