Fuse link CH10x38 MM 20A/1000V AC/DC 002625407

Specifications

ETI Code:
002625407
Description:
CH10x38 MM 20A/1000V AC/DC
Class name:
Fuse link
efuse:
1
Type:
CH
Size:
CH10
Rated current (A):
20
Rated DC voltage (V):
1000
Characteristics:
gR
Breaking capacity DC (kA):
30
Application:
Multimeter fused
Dimensions:
10x38
Power dissipation (W):
3,15
Standards:
IEC 60269-4

Documents

Product

EAN code for a single product
3838400060976
Net weight of the product
8.3  g
Customs tariff
85361050
logis_net_width
10  mm
logis_net_height
38  mm
logis_net_depth
10  mm

Level 1 Packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838895700029
Basic packaging weight
0.08  kg

Level 2 Packaging

Transport packaging quantity
500
EAN code for a transport packaging
3838895700036
Transport packaging weight
4.1  kg
Pallet quantity
84000
Classification
EC002704
Class name
Cylindrical fuse
Rated current
20
Max. rated operation voltage Ue AC
1000
Construction size
CH10
Rated voltage DC
1000
Application
Multimeter fused
Utilization category
Other
Breaking capacity
30kA
ETIM Classification – Version 7.0
